Specifications:

CC2541 Slave Bluetooth

BLE5.0 Bluetooth Transparent Bluetooth data transimission

Based on Bluetooth 5.0 protocal standard, working on 2.4Ghz in GFSK mode.

Maximum transmitting power: 4dB

Maximum transmitting distance: 60 Meters

I/O interface: UART

Working Voltage: 1.8~3.6V

Working Temp.: -40 ~ 80℃

Antenna: Bulit-in PCB Antenna

Receiving Sensitivity: -97dbm

Master-Slave Support: Slave

Awakening State Current: 800uA

Deep Sleep Current: 9uA

RF-TX/RX Peak current: 5mA

Pin definition:

Pacakge includes:

1 X Mini Bluetooth 5.0 Module work in TTL Signal

Note: all the descriptions and prices are subject to change without prior notice.
