Overview

The AT24CXX EEPROM Board is a storage tool for EEPROM with I2C interface, It is a non-volatile memory module. By using the onboard pinheader and female connector, several AT24CXX EEPROM Board can be cascaded on the I2C bus.

Schematic:

eeprom.pdf

AT24C02B.pdf

Code:

code.zip

Package includes:

1 X A tool for EEPROM with I2C interface, AT24Cxx on board
