300M Wireless USB Network Card WiFi Adapter Dual Band 2.4G 5G Signal Receiver WiFi Dongle Ralink RT5572 Supports Linux

Specifications:

Main Chipset: Ralink RT5572N

Host interface: USB 2.0 Type A

LEDs: None

Antennas: 2 built-in onboard 2.4/5 GHz PCB antennas.

Operation Frequency: ISM band , 2412~2483.5MHz , 4915~5825MHz(Detail frequency range depends on country region).

Typical Transmit Power (before antenna):

  • 802.11a (OFDM) 54Mbps: 10+/-1dBm

  • 802.11b (CCK) 11Mbps: 18+/-1dBm

  • 802.11g (OFDM) 54Mbps: 15+/-1dBm EVM <-31dB

  • 802.11n (HT20 MCS7), 15+/-1dBm,(HT40 MCS15),14+/-1dBm

Receive Sensitivity (after antenna):

  • 802.11a: -66+/-1dBm

  • 802.11b: -88+/-1dBm

  • 802.11g: -73+/-1dBm

  • 802.11n (HT20), -70+/-1dBm;802.11n (HT40), -72+/-1dBm

Security: WEP 64/128, WPA/WPA2 (TKIP,AES); WAPI;

Voltage Range/Current: DC 5.0V ± 5% / <330mA  802.11g;3.3VDV± 5% <350mA,  802.11n,HT40


Package Includes:
1 X Wireless USB network card


MDL.1359

10

1pcs/lot
