Hardware Specifications
Chipset	ESPRESSIF-ESP32-DOWDQ6 240MHz Xtensa® single-/dual-core 32-bit LX6 microprocessor
FLASH	QSPI flash/SRAM, up to 4 x 16 MB
SRAM	520 kB SRAM +  8MBytes External SPRAM
KEY	reset
dispaly	IPS Panel ST7789/1.3 Inch
Power indicator lamp	red
USB to TTL	CP2104
Camera	OV2640  2Megapixel
on-board clock	40MHz crystal oscillator
working voltage	2.3V-3.6V
working current	about 160mA
working temperature range	-40℃ ~ +85℃
size	69.13*28.41*8.45mm
Mic	MSM261S4030H0
SDCard	Integrated external SD card slot
Power management Chip	IP5306
Power Supply	USB 5V/1A
charging current	1A
battery	3.7V lithium battery
WIFI	Description
Standard	FCC/CE/TELEC/KCC/SRRC/NCC
protocol	802.11 b/g/n/e/i (802.11n，speed up to150Mbps)A-MPDU and A-MSDU polymerization，support 0.4μS Protection interval
frequency range	2.4GHz~2.5GHz(2400M~2483.5M)
Transmit Power	22dBm
communication distance	300m
Bluetooth	Description
protocol	meet bluetooth v4.2BR/EDR and BLE standard
radio frequency	with -98dBm sensitivity NZIF receiver Class-1,Class-2&Class-3 emitter AFH
audio frequency	CVSD&SBC audio frequency
Software specification	Description
wifi Mode	Station/SoftAP/SoftAP+Station/P2P
security mechanism	WPA/WPA2/WPA2-Enterprise/WPS
Encryption Type	AES/RSA/ECC/SHA
firmware upgrade	UART download/OTA（Through network/host to download and write firmware）
Software Development	Support cloud server development /SDK for user firmware development
networking protocol	IPv4、IPv6、SSL、TCP/UDP/HTTP/FTP/MQTT
User Configuration	AT + Instruction set, cloud server, android/iOSapp
OS	FreeRTOS

Package includes:

1 X TTGO T-Camera Plus ESP32-DOWDQ6 8MB SPRAM Camera Module OV2640 1.3 Inch Display Rear Camera Fish-eye Lens
